Diesel generator sets
DE1000S GC
Producing reliable power at 1000 ekW, 60 Hz, our DE1000S GC diesel generator set is made to meet your needs in standby applications. We've designed each to ISO 8528-5 transient response requirements and to accept 100% rated load in one step. This generator set offers a low fuel consumption system.
- Maximum Rating1000 eKW
- Minimum Rating1000 eKW
- Emissions/Fuel StrategyLow Fuel Consumption
- Voltage380 - 480 Volts
- Frequency60 Hz
- Duty CycleStandby
| Maximum Rating | 1000 eKW |
|---|---|
| Minimum Rating | 1000 eKW |
| Emissions/Fuel Strategy | Low Fuel Consumption |
| Voltage | 380 - 480 Volts |
| Frequency | 60 Hz |
| Speed | 1800 rpm |
| Duty Cycle | Standby |
| Engine Model | C32B TA, V-12, 4-Stroke Water-Cooled Diesel |
|---|---|
| Bore | 5.71 in |
| Stroke | 6.38 in |
| Displacement | 1958.86 in³ |
| Compression Ratio | 15.0:1 |
| Aspiration | TA |
| Fuel System | EUI |
| Governor Type | Adem™A4 |
| Length - Minimum | 164.3 in |
|---|---|
| Length - Maximum | 164.3 in |
| Width - Minimum | 73.1 in |
| Width - Maximum | 73.1 in |
| Height - Minimum | 87.3 in |
| Height - Maximum | 87.3 in |
| Dry Weight - Genset (minimum) | 14669 lb |
| Dry Weight - Genset (maximum) | 14669 lb |
Control Panel
- GCCP1.3
Cooling System
- Radiator
-
Download ↓Electric Power Ratings Guide
-
Download ↓DE1000S GC, C32B, 60 Hz 1250 ekW, Optimised for Low Fuel Consumption Spec Sheet
Need installed dimensions with enclosure and tank? See Model Configurations
